Features
It is widely used in 10GEPON/XGPON/XGSPON and RF networks
Depending on the configuration, up to 6 wavelengths of PON system power can be tested simultaneously: 1490nm, 1550nm, 1577nm, 1310nm, 1270nm, 1610nm
Can test 1310nm, 1270nm, 1610nm burst mode uplink wavelength signal
Provides 10 sets of threshold values for operator selection, analysis and display of pass and failure status relative value selection and editing function can save 1000 records
Manually set thresholds, upload data and calibrate wavelengths.
Visual fault locator function
Self-calibration function
Automatic shutdown function
Automatic backlight function
Large capacity lithium battery
Energy-saving design, low-voltage self-test power off
HD screen, clear to read in outdoor sunlight
Specifications
Wavelength(nm) | 1310 (uplink) | 1490 (downlink) | 1550 (downlink) | 1270 (uplink) | 1577 (downlink) | 1610 (uplink) |
Spectral passband(nm) | 1290-1330 | 1470-1505 | 1535-1570 | 1260-1280 | 1577±3nm | 1595-1650 |
Range(DBM) | -40-+10 | -45-+10 | -45-+10 | -40-+10 | -45-+10 | -40-+10 |
Isolation@1310nm(dB) | >40 | >40 | >40 | >40 | >40 | |
Isolation@1490nm(dB) | >40 | >40 | >40 | >40 | >40 | |
Isolation@1550nm(dB) | >40 | >40 | >40 | >40 | >35 | |
Isolation@1270nm(dB) | >40 | >40 | >40 | >40 | >40 | |
Isolation@1577nm(dB) | >40 | >40 | >40 | >40 | >40 | |
Isolation@1610nm(dB) | >40 | >40 | >40 | >40 | >40 | |
Accuracy | ||||||
Uncertainty | ±0.5dB | |||||
Polarization Loss | <±0.25dB | |||||
Linear | ±0.1dB | |||||
Insertion Loss | <1.5dB | |||||
Display Resolution | 0.01dB | |||||
Unit | dBm/xW | |||||
LCD | 320*240, 3.2 inch True color LCD screen | |||||
Battery | 4.2V 2400mAh rechargeable battery | |||||
Battery working time | 20 hours around | |||||
Operating Temperature | 0～60℃ | |||||
Storage Temperature | 25～70℃ | |||||
Size(mm) | 155×85×40 | |||||
Weight(g) | 300 | |||||
