Light Source FFS301 is advanced two-color integrated mold process for extra durability, Top dust-proof over protects the fiber output connector.
Features
Support cw and a variety of modulation light output
Output optical power adjustable, Adjustment range 6dB, step 1dB (optional).
Support automatic shutdown
Backlight intelligent control
Supports single wavelength, combined wavelength customization (1490nm, 1625nm)
Specifications
LS | ||
Wavelength | 850nm±20nm/1300nm±20nm | 1310nm/1490nm/1550nm±20nm |
Fiber Type | 62.5/125um | 9/125um |
Laser type | FP-LD | |
Power | ≤-5dBm | |
Stability | ±0.02dB/8h | |
Mode | CW, 270Hz/1kHz/2kHz | |
Power Regulation | 0-6dB, 1dB step | |
Connector | FC/SC/ST | |
Others | ||
Power Supply | 3pcs AA battery/1500mAh Lithium battery(optional) | |
Automatic shutdown time | 10min | |
Continuous working time | ≥72h(LS function) | |
Operating temperature | -10~+50℃ | |
Storage temperature | -40~+70℃ | |
Working humidity | 0~95% Non condensing | |
Size | 186mm x100mm x50mm | |
Weight | 140g/150g | |
