Features
Compact size
Visual reading
Ultra low insertion loss
Innovative integrated fixture
500mAh lithium battery
Type-C charging interface
Wireless Bluetooth(optional)
Specifications
Identify wavelength range | 800-1700nm |
Detector type | 1mm, InGaAs, 2pcs |
Applicable fiber type | Φ0.25mm, Φ0.9mm, Φ2.0mm, Φ3.0mm(for pigtails) |
Modulation frequency | CW, 270Hz, 1kHz, 2kHz |
Signal direction indication | Left and right LED direction indicators |
Signal direction detection range | -40-+10dBm |
Frequency detection range | ≥-20dBm |
Insertion Loss(Typ.) | ≤1dB |
Battery | 3.7V/500mAh Lithium battery |
Battery working time | 24h |
Working temperature | -10°C-+50℃ |
Storage temperature | -40℃-+70℃ |
Size | NK430:82x43x29mm; NK432:79x43x23mm |
