Features
Compact design with light weight
High Precision CNC Cleaver
Metal Rail made in japan
93A Tungsten Steel Casting sharp Blade
Wide Cleaver OD:250um coated fiber or 900um buffered fiber
12 Position Rota-table and Replaceable Blade
Attached with PVC dustbin to collect scrapped blade and fiber
Apply for both single mode and multi mode
Specifications
Bare fiber diameter | 0.25mm~0.9mm |
Coating diameter | 125µm |
Fiber type | Single tube fiber and Ribbon fiber(exchangeable) |
Cleaved length | 9~16mm(φ0.25) 10~16(φ0.9) |
Cleaved angle | ≤0.5° |
Blade life | 48,000cleaves |
Mode | Semiautomatic |
Dimension | 63mm(W)*76mm(D)*63mm(H) |
Weight | 430g |
